Specification
| CPU | ARM Cortex-A72(1.8GHz) x 2 and ARM Cortex-A53( (1.4GHz) ) x 4 |
|---|---|
| RAM | LPDDR3 2Gbyte x 2 |
| FLASH | eMMC 8Gbyte |
| OS | Ubuntu 18.04 LTS |
| Ethernet Ⅰ | Gigabit Ethernet Controller 10/100/1000Mbps |
| Ethernet Ⅱ | USB to Ethernet Controller 10/100/1000Mbps |
| USB HOST Ⅰ | USB 3.0 High-Speed 4CH (1CH image download) |
| USB HOST Ⅱ | USB 2.0 2CH |
| PCIE | M.2 SATA |
| HDMI | 1CH (해상도 1920x1080) |
| RS-485 | 1CH |
| AUDIO | 1CH |
| CONSOLE | 1CH |
| mSD | SDIO Inerface |
